Camso ATV R4S TRACK
Product number:
H242-ZZ-1616
Product information "Camso ATV R4S TRACK"
An all-season ATV track system designed for small 4x4 ATVs with 300-500 ccm engines. Ground pressure reduced by 50% vs. tires. The ATV R4S is the perfect track system to take your ATV further than ever before. Truly all year-round use: winter, spring, summer; works on snow, mud, gravel and sand. Significantly more affordable compared to snowmobile, plus ability to ride on snow-free surfaces. Easy installation.
Features:
For small 4x4 ATVs with 300-500 ccm engine
Robust design
Ground pressure reduced by 50% vs. tires
Great stability and easy handling
Excellent traction over any terrain
Superior flotation
Solid carbon-steel frame
Durable powder coated finish
Double bearings
Quick and easy installation and removal
Note: Adapters are not included and must be ordered separately for your model.
Technical specifications Camso R4S Track system
Weight
27 kg (Front)
Features:
For small 4x4 ATVs with 300-500 ccm engine
Robust design
Ground pressure reduced by 50% vs. tires
Great stability and easy handling
Excellent traction over any terrain
Superior flotation
Solid carbon-steel frame
Durable powder coated finish
Double bearings
Quick and easy installation and removal
Note: Adapters are not included and must be ordered separately for your model.
Technical specifications Camso R4S Track system
Weight
27 kg (Front)
27 kg (Rear)
Width
276 mm (Front)
276 mm (Rear)
Length
1016 mm (Front)
1092 mm (Rear)
Height
610 mm (Front)
610 mm (Rear)
Ground surface 0.86 m²
Lug height
22 mm (Front)
25 mm (Rear)
Ground clearance increase by 83 mm
Speed reduction cca 1/3
Frame
Carbon steel open frame
Idler & Mid-roller wheels 134 mm
Double bearing
Sealed mid-roller wheels
The data is for information only. Subject to change.
Width
276 mm (Front)
276 mm (Rear)
Length
1016 mm (Front)
1092 mm (Rear)
Height
610 mm (Front)
610 mm (Rear)
Ground surface 0.86 m²
Lug height
22 mm (Front)
25 mm (Rear)
Ground clearance increase by 83 mm
Speed reduction cca 1/3
Frame
Carbon steel open frame
Idler & Mid-roller wheels 134 mm
Double bearing
Sealed mid-roller wheels
The data is for information only. Subject to change.
